Product Characteristics
- Thermal Performance
Ultra-low thermal capacity and thermal conductivity
Excellent thermal stability (resists pulverization at high temperatures)
- Chemical & Structural Properties
Superior chemical stability (resistant to oxidation/neutral/reducing atmospheres)
Binder-free and non-adherent composition (no corrosive substances)
- Functional Advantages
Outstanding sound absorption capability
High tensile strength and slag-free structure
Typical Applications
- Industrial furnace lining materials13
- High-temperature pipeline insulation35
- Expansion joint sealing in kiln structures and furnace door covers13
Modular fabrication materi
| Classification temperature (℃) | 1050 | 1260 | 1400 | 1600 | ||||
| Item Code | YSTX-112 | YSTX-212 | YSTX-312 | YSTX-412 | YSTX-512 | YSTK-612 | YSJT-712 | |
| Heating permanent line change (%) | 950℃×24h s-3 | 1000°℃x24h s-3 | 1100℃x24h s-3 | 1200℃x24h s-3 | 1350℃×24h 8-3 | 1250℃×24h s-3 | 1500Cx24h
≤-3 |
|
| Theoretical heat transfer system /(m ·k) | A.V.E(500℃)≤0.153 | |||||||
| Bulk density (kg/m³) | 96/128 | |||||||
| Tensile strength (MPa) | 0.04 | >0.05 | >0.05 | ≥0.05 | ||||
| Chemical composition | AL,0,(%) | =43 | ≥45 | ≥45 | ≥52 | 36 | =41 | s72 |
| SiO₂ (%) | >52 | ≥52 | 54 | 46 | 248 | >52 | >25 | |
| Zr0₂ (%) | – | – | – | — | =15 | ≥5 | — | |
| Fo₂0,(%) | 1.0 | =0.8 | =0.2 | =0.2 | =0.2 | =0.2 | =0.2 | |
| AL20+Si0,(S) | >96 | >97 | >99 | >99 | — | — | >99 | |
| AL,0+Si0₂+Zr0₂ (%) | — | 一 | 一一 | – | ≥99 | ≥98 | – | |
| 3600/5000/7200/21000*610/1220*10/20/30/50 | ||||||||
